"T-type 4-in-1 Branch Bus Connectors: Escort for photovoltaic Systems"
Photovoltaic power generation, as a representative of clean energy, has developed rapidly in recent years, especially in large-scale centralized photovoltaic power plants and distributed photovoltaic applications playing an increasingly important role. With the continuous expansion of the scale of photovoltaic systems, system safety and reliability are also concerned. As an important part of the photovoltaic system, the performance of the connector directly affects the stable operation of the entire photovoltaic power station.
Today, we will talk about the MC410-4M4FPLN01 T-type 4-in-1 branch bus connector from SHUNKONN Technology, which provides strong protection for photovoltaic systems with excellent performance parameters and reliable safety.
The MC410-4M4FPLN01 is a T-type 4-in-1 branch bus connector from SHUNKONN Technologies, specially designed for large-scale photovoltaic power plants. The main features of the product are as follows:
(Click on the picture for details)
Rated voltage 1000V, rated current 50A
The MC410-4M4FPLN01 has a rated voltage of up to 1000V, making it more suitable for high voltage and large capacity photovoltaic systems than ordinary photovoltaic connectors. At the same time, its 50A rated current can also meet the large current needs of large photovoltaic power stations for connectors. This excellent electrical performance also gives it significant advantages in terms of safety and reliability.
Tinned copper conductor, contact resistance ≤0.35mΩ
The product uses tinned copper conductor, which not only has excellent electrical conductivity, but also has strong corrosion resistance to ensure long-term reliable operation. Contact resistance as low as 0.35 milliohms minimizes on-off losses and further increases system efficiency.
T-type 4-in-1 branch design
Unlike the traditional Y-branch, the MC410-4M4FPLN01 adopts a T-type 4-in-1 branch structure. This design not only realizes the high integration of the line, but also more in line with the installation layout needs of photovoltaic power stations, simplifies the on-site wiring, and improves the installation efficiency. At the same time, the T-branch can also better ensure the balanced distribution of various currents, and effectively prevent overheating and other problems caused by current imbalance.
UL94-V0 flame retardant rating,IP68 waterproof rating
MC410-4M4FPLN01 has passed the UL94-V0 flame retardant performance test and has excellent fire resistance. At the same time, its shell design reaches IP68 waterproof rating, even in harsh outdoor environments, it can ensure reliable protection performance and effectively avoid safety hazards caused by water vapor intrusion.
Passed CE certification
The product has passed CE certification and meets relevant international safety standards to ensure its safety and quality reliability.
Application scenario
MC410-4M4FPLN01 is mainly used in large-scale centralized photovoltaic power plants and distributed photovoltaic power plants, especially for the following scenarios:
Large surface power station
In the large ground power station, the T-type 4-in-1 branch design of MC410-4M4FPLN01 can effectively simplify the field wiring and improve the construction efficiency. At the same time, its excellent protection performance can also ensure the long-term safe and stable operation of the power station.
Centralized photovoltaic power station
Centralized photovoltaic power stations usually have large system capacity and high electrical performance requirements for connectors. The MC410-4M4FPLN01, with its excellent 1000V high voltage and 50A high current performance, is ideal for applications in such power stations.
Distributed photovoltaic power station
In distributed photovoltaic power plants, the T-type 4-in-1 design of the MC410-4M4FPLN01 can effectively reduce the number of connections between components, greatly improving the overall beauty and safety. At the same time, its high protection level can also ensure reliable operation in harsh outdoor environments.
In general, the MC410-4M4FPLN01 is a high-performance T-type 4-in-1 branch bus connector customized for large-scale photovoltaic power plants. With excellent electrical performance, excellent safety protection and international quality certification, it protects the safe and reliable operation of photovoltaic systems. In the future, with the continuous expansion of the scale of photovoltaic power stations, I believe that high-end photovoltaic connectors such as MC410-4M4FPLN01 will occupy a more important position in the industry.
